385430-86, ERN430 2048 27S12-03 R 0.00 .. 70C14 64 01, Heidenhain incremental rotary encoder

385430-86, ERN430 2048 27S12-03 R 0.00 .. 70C14 64 01, Heidenhain incremental rotary encoder

Product details:
ERN 430
Incremental rotary encoder with integral bearing for mounting by stator coupling
Line count:              2048
Output signal:           HTL
Max. scanning frequency: 300.00 kHz
Power supply:            10V ... 30V
Coupling version:        Stator coupling for plane                         surface (hole circle Ø 63
mm)
Shaft:                   Hollow through shaft with clamping ring usable on both sides, diameter 12mm
Protection rating:       IP64 (EN60529)
Operating temperature:   -40/+100°C
Electrical connection:   Flange socket M23, male, 12-pin
Pin configuration:       D294999
Connecting direction:    radial
Included parts:           no enclosed part

Price, delivery time, condition, warranty, options:
a.) selling price for a fully refurbished engine: 775EUR ( 309 501 HUF) 1 year warranty, delivery time: 2-12 weeks to Hungary, 2-12 weeks arrival (to Western and Central Europe), UA (2-12 weeks), UAE (2-12 weeks), USA (2-12 weeks)
(For urgent machine downtime, information: the device can be delivered relatively quickly (within 1-2 weeks), for a one and a half times higher price.)

b.) repair price: EUR (HUF), 2 year warranty.
Standard repair time: 12 days delivery time to Hungary, 12 days delivery time (to Europe), UA (12 days), UAE (15 days), USA (16 days).
For urgent repairs, we can complete the repair within ~48 hours.
