ATV31HU55N4, VSD drive, 5.5 kW 4 kHz, Schneider Electric

ATV31HU55N4, VSD drive, 5.5 kW 4 kHz, Schneider Electric

Product details:
Product family: Altivar
Product or component type: Variable speed drive
Product specific application: Simple machine
Part name: ATV31
Mounting type: With cooling fin
EMC filter: Integrated
[Us] rated supply voltage: 380...500 V - 5...5 %
Supply frequency: 50...60 Hz - 5...5 %
Number of network phases: 3 phases
Motor power kW: 5.5 kW 4 kHz
Motor power HP: 7.5 HP 4 kHz
Mains current: 16.5 A at 500 V 21.9 A at 380 V, Isc = 1 kA
Apparent power: 15 kVA
Expected wire Isc : 1 kA
Nominal output current : 14.3 THE 4 kHz
Maximum transition current : 21.5 THE 60 for seconds
Power consumption W - in : 232 W nominal under load
Asynchronous engine control profile : Factory set : permanent torque
Sensor without flux vector - control PWM type engine controller with indication

Price, delivery time, condition, warranty, options:
a.) selling price for a refurbished module: 580 EUR
In case of machine downtime, we will deliver the next day!

b.) repair price: 850 EUR (333792 HUF)
2 year warranty. Standard repair time: 12 days delivery time to Hungary, 12 days delivery time to Europe, UA 13 days, UAE 15 days, USA 16 days.
For urgent repairs, we can complete the repair within ~48 hours.
