DT71D4/BMG/TF/ASD1, 0.37 kW three-phase AC motor, (brake/BMG/), SEW-Eurodrive

DT71D4/BMG/TF/ASD1, 0.37 kW three-phase AC motor, (brake/BMG/), SEW-Eurodrive

Price, delivery time, condition, warranty, options:
a.) selling price for refurbished module: 430EUR
2 year warranty, delivery time: 6 days to Hungary, 6 days to Western and Central Europe, UA 9 days, UAE 14 days, USA 14 days.
1 piece available from stock.

Product details:
Voltage: 50Hz V 220-240D / 380-415 Y - 60Hz, V 240-266D/415-460Y
Power: 0.37kW
Current consumption: A 2.15 / 1.24 – 1.95 / 1.12
Speed: 1380rpm
Brake motor: /BMG/ in the article number.

The DT71D4/BMG/TF/ASD1 part number means:

DT71D4
DT: AC, squirrel cage, induction motor series
71: Frame size 71
D4: 4-pole motor (~1350–1400 rpm at 50 Hz)

BMG
Designation of a spring-loaded electromagnetic brake mounted on the motor shaft.
The brake engages when the power supply is interrupted and releases when the power supply is restored.

TF
Thermal protection in the coils (PTC thermistor).

ASD1
Optional configuration code (usually related to the junction box / wiring / brake rectifier configuration, depending on the production version).
