385430-30, ERN430 2048 27S12-03, Heidenhain incremental encoder

385430-30, ERN430 2048 27S12-03, Heidenhain incremental encoder

Product details:
ERN 430
Incremental rotary encoder with integral bearing
for mounting by stator coupling
Line count: 2048
Output signal: HTL
Max. scanning frequency: 300.00 kHz
Power supply: 10V ... 30V
Coupling version: Stator coupling for plane
surface (hole circle Ø 63
mm)
Shaft: Blind hollow shaft with
clamping ring, diameter
12 mm, depth 24 mm
Protection rating: IP64 (EN60529)
Operating temperature: -40/+100 °C
Electrical connection: Flange socket M23, male,
12-pin
Pin configuration: D294999
Connecting direction: radial
Included part: no enclosed part

Price, delivery time, condition, warranty, options:
a.) selling price for a new encoder: 580EUR ( 231 626 HUF) 1 year warranty, delivery time: 3-12 weeks to Hungary, 3-12 weeks arrival (to Western and Central Europe), UA (3-12 weeks), UAE (3-12 weeks), USA (3-12 weeks)
(info: in an urgent situation, if the machine is down, we can deliver the module within ~1 week, for 1.5x the selling price)

b.) repair price: EUR (HUF), 1 year warranty.
Standard repair time: 12 days delivery time to Hungary, 12 days delivery time (to Europe), UA (12 days), UAE (15 days), USA (16 days).
For urgent repairs, we can complete the repair within ~48 hours.
