HCS01.1E-W0005-A-03-E-S3-EC-NN-NN-NN-FW, Rexroth Indramat

HCS01.1E-W0005-A-03-E-S3-EC-NN-NN-NN-FW, Rexroth Indramat

Product details:
Control unit power : ECONOMY
Maximum current : 5 A
Control panel With the standard control panel , firmware must be ordered separately .
Continuous current : 2 A
Cooling type : Internal air cooling
Supply voltage ( 3 AC ): 200 - 500 V
Switching frequency / max . output frequency (@ 4kHz ): 0 - 400 Hz
Nominal mains frequency: 50-60 Hz
Switching frequency / max. output frequency (@8kHz): 0-800 Hz
Switching frequency / max. output frequency (@12kHz): 0-1200 Hz
Switching frequency / max. output frequency (@16kHz): 0-1600 Hz
Interface encoder: 1 multi-encoder interface
Output voltage: 3 x AC 0…500 V
Interface encoder 2: Not defined
Predefined communication protocol: Sercos III/EtherCAT®
Maximum power (without choke): 1.38 kW
Continuous power (without choke): 0.46 kW

Price, delivery time, condition, warranty, options:
a.) selling price for refurbished module: 1090 EUR
2 year warranty, delivery time: 9 days to Hungary, 9 days to Western and Central Europe, UA 12 days, UAE 14 days, USA 14 days.

b.) repair price: 900 EUR (343117 HUF)
2 year warranty. Standard repair time: 12 days delivery time to Hungary, 12 days delivery time to Europe, UA 13 days, UAE 15 days, USA 16 days.
For urgent repairs, we can complete the repair within ~48 hours.
